Environment Variables
ToolJet requires several environment variables to function properly. Below is a simplified guide to setting them up.
ToolJet Server
Required Variables
ToolJet Host
TOOLJET_HOST
: Public URL of ToolJet (e.g.,https://app.tooljet.ai
)
Lockbox Configuration
LOCKBOX_MASTER_KEY
: 32-byte hex string for encrypting datasource credentials- Generate using:
openssl rand -hex 32
- Generate using:
Application Secret
SECRET_KEY_BASE
: 64-byte hex string for encrypting session cookies- Generate using:
openssl rand -hex 64
- Generate using:
Database Configuration
PG_HOST
: PostgreSQL database hostPG_DB
: Database namePG_USER
: UsernamePG_PASS
: PasswordPG_PORT
: Port
Docker Compose Setup: If you are using a Docker Compose setup with an in-built PostgreSQL instance, set PG_HOST
to postgres
. This ensures that Docker's internal DNS resolves the hostname correctly, allowing the ToolJet server to connect to the database seamlessly.
Database Connection URL: If you intend to use the database connection URL and your database does not support SSL, use the following format when setting the DATABASE_URL
variable:
DATABASE_URL=postgres://PG_USER:PG_PASS@PG_HOST:5432/PG_DB?sslmode=disable
Replace username
, password
, hostname
, port
, and database_name
with your actual database details.
Disabling Automatic Database & Extension Creation (Optional)
PG_DB_OWNER=false
: ToolJet by default tries to create database based onPG_DB
variable set and additionally my try to create postgres extensions. This requires the postgres user to haveCREATEDB
permission. If this cannot be granted you can disable this behaviour by settingPG_DB_OWNER
asfalse
and will have to manually run them.
ToolJet Database
TOOLJET_DB
: Default database name (tooljet_db
)TOOLJET_DB_HOST
: Database hostTOOLJET_DB_USER
: Database usernameTOOLJET_DB_PASS
: Database passwordTOOLJET_DB_PORT
: Database port
Automatic Database Creation: The database name specified in TOOLJET_DB
will be automatically created during the server boot process in all production deployment setups.
PostgREST
ToolJet uses PostgREST (v12.2.0) for API access. The following environment variables are required for PostgREST:
PGRST_JWT_SECRET
: JWT secret (Generate usingopenssl rand -hex 32
). If this parameter is not specified, PostgREST will refuse authentication requests.PGRST_DB_URI
: Database connection stringPGRST_LOG_LEVEL=info
If you intent to make changes in the above configuration. Please refer PostgREST configuration docs.
Configuring PGRST_DB_URI
PGRST_DB_URI
is required for PostgREST, which is responsible for exposing the database as a REST API. It must be explicitly set to ensure proper functionality.
This follows the format:
PGRST_DB_URI=postgres://TOOLJET_DB_USER:TOOLJET_DB_PASS@TOOLJET_DB_HOST:5432/TOOLJET_DB
Ensure that:
username
andpassword
match the credentials for the PostgREST database user.hostname
is correctly set (postgres
if using Docker Compose setup with an in-built PostgreSQL).port
is the PostgreSQL port (default:5432
).database_name
is the database used for PostgREST (tooljet_db
in this example).
Redis Configuration
Include the following Redis environment variables within the ToolJet deployment only if you are connecting to an external Redis instance (v6.2) for a multi-service or multi-pod setup and have followed the necessary steps to create Redis.
REDIS_HOST=
REDIS_PORT=
REDIS_USER=
REDIS_PASSWORD=
Optional Configurations
Comments Feature
COMMENT_FEATURE_ENABLE=true/false
: Use this environment variable to enable/disable the feature that allows you to add comments on the canvas. To configure this environment variable, ensure that multiplayer editing is enabled in the Settings.
User Session Expiry
USER_SESSION_EXPIRY
: Controls session expiry time (in minutes). Default: 10 days.
Note: The variable expects the value in minutes. ex: USER_SESSION_EXPIRY = 120 which is 2 hours
Password Retry Limit
By default, an account is locked after 5 failed login attempts. You can control this with:
DISABLE_PASSWORD_RETRY_LIMIT=true
: Disables the retry limit.PASSWORD_RETRY_LIMIT=<number>
: Sets a custom retry limit (default is 5).
Hide Account Setup Link
HIDE_ACCOUNT_SETUP_LINK
: Set totrue
to hide the account setup link from the admin in the manage user page. Ensure SMTP is configured to send welcome emails.
Restrict Signups
Set DISABLE_SIGNUPS=true
to allow only invited users to sign up. The signup page will still be visible but unusable.
SMTP Configuration
ToolJet sends emails via SMTP.
If you have upgraded from a version prior to v2.62.0, the SMTP variables in your .env file will automatically be mapped to the UI. For versions v2.62.0 and later, SMTP configuration will no longer be picked up from the .env file for Enterprise Edition. You must configure SMTP through the UI. You can safely remove these variables from your .env file after ensuring that the configuration is properly set up in the UI.
For Enterprise Edition, configure SMTP in the ToolJet Settings UI.
For Community Edition, use these environment variables:
DEFAULT_FROM_EMAIL
: Sender email addressSMTP_USERNAME
: SMTP usernameSMTP_PASSWORD
: SMTP passwordSMTP_DOMAIN
: SMTP hostSMTP_PORT
: SMTP port
Custom CA Certificate
If ToolJet needs to connect to self-signed HTTPS endpoints, ensure the NODE_EXTRA_CA_CERTS
environment variable is set to the absolute path of the CA certificate file.
NODE_EXTRA_CA_CERTS=/path/to/cert.pem
: Absolute path to the PEM file (can contain multiple certificates).
Third-Party Integrations
Slack
To use Slack as a data source in ToolJet, create a Slack app and set:
SLACK_CLIENT_ID
: Slack app client IDSLACK_CLIENT_SECRET
: Slack app client secret
Google OAuth
To connect ToolJet with Google services like Google Sheets, create OAuth credentials in Google Cloud Console.
GOOGLE_CLIENT_ID
: Google OAuth client IDGOOGLE_CLIENT_SECRET
: Google OAuth client secret
Google Maps API
To use the Maps widget in ToolJet, create a Google Maps API key and set:
GOOGLE_MAPS_API_KEY
: Google Maps API key
Application Monitoring (APM)
APM_VENDOR=sentry
: Set APM vendor.SENTRY_DNS
: Sentry project DSN.SENTRY_DEBUG=true/false
: Enable/disable Sentry debugging.
Security & Authentication
By default, ToolJet sends user count updates every 24 hours. To disable this, use:
DISABLE_TOOLJET_TELEMETRY=true
: Disables telemetry.(Enabled by default)
Single Sign-On (SSO)
Enable Google or GitHub SSO with these environment variables:
Google SSO:
SSO_GOOGLE_OAUTH2_CLIENT_ID
: Google OAuth client ID
GitHub SSO:
SSO_GIT_OAUTH2_CLIENT_ID
: GitHub OAuth client IDSSO_GIT_OAUTH2_CLIENT_SECRET
: GitHub OAuth client secretSSO_GIT_OAUTH2_HOST
: GitHub host if self-hosted
General SSO Settings:
SSO_ACCEPTED_DOMAINS
: Comma-separated list of allowed email domainsSSO_DISABLE_SIGNUPS=true
: Restricts signups to existing users
REST API Cookie Forwarding
By default, ToolJet does not forward cookies with REST API requests. To enable this (self-hosted only), set:
FORWARD_RESTAPI_COOKIES=true
: Allows forwarding cookies with REST API requests.
Asset Path
This is required when the assets for the client are to be loaded from elsewhere (eg: CDN). This can be an absolute path, or relative to main HTML file.
ASSET_PATH
: Path for loading frontend assets (e.g.,https://app.tooljet.ai/
)
Additional Configurations
Log File Path
LOG_FILE_PATH
: Path to store audit logs (e.g.,tooljet/log/tooljet-audit.log
)
Embedding Private Apps
By default, only public apps can be embedded. To allow embedding of private ToolJet apps, set:
ENABLE_PRIVATE_APP_EMBED=true/false
: Allows embedding of private ToolJet apps.
Note: Available in ToolJet Enterprise 2.8.0+ and Community/Cloud 2.10.0+.
Default Language
Set the default language using the LANGUAGE
variable. Supported options:
Language | Code | Native Name |
---|---|---|
English | en | English |
French | fr | Français |
Spanish | es | Español |
Italian | it | Italiano |
Language | Code | Native Name |
---|---|---|
Indonesian | id | Bahasa Indonesia |
Ukrainian | uk | Українська |
Russian | ru | Русский |
German | de | Deutsch |
Example: LANGUAGE=fr
(for French).
Note: This setting is not available in ToolJet Cloud.
